Standard Quest Float Suite Dimensional Schematic

These are the dimensional schematics of the Standard Quest Float Suite.

Weight for the individual parts are as follows:

          Tub - 112 lbs

          Long Side Wall - 74.5 lbs

          Short Side Wall - 42 lbs

PDF Link:  Standard Quest Float Suite Dimensional Schematic
